BOYALI PROFİL

DİKDÖRTGEN PROFİLLER BİRİM AĞIRLIK TABLOSU

Ebat Et Kalınlığı
  0,8mm 0,9mm 1,00mm 1,2mm 1,5mm 2,00mm 2,5mm 3,00mm 4,00mm 5,00mm 6,00mm
10x20 0,356 0,399 0,420 0,520
10x30 0,482 0,539 0,580 0,708 0,830
15x25 0,482 0,539 0,580 0,708 0,830
20x30 0,608 0,681 0,753 0,896 1,070 1,380
20x40 0,733 0,822 0,890 1,085 1,300 1,680
25x40     0,970 1,180 1,420 1,850
30x40     1,050 1,273 1,540 2,010
30x50     1,210 1,462 1,780 2,310 2,820 3,300 4,200
40x60       1,810 2,250 2,930 3,600 4,250 5,450 6,560
40x80           3,560 4,390 5,190 6,710 8,130
40x100           4,190 5,170 6,130 7,970 9,700
50x70           3,560 4,390 5,190 6,710 8,130
50x90           4,190 5,170 6,130 7,970 9,700
50x100               6,600 8,590 10,500
60x80           4,190 5,170 6,130 7,970 9,700
60x100             5,960 7,070 9,220 11,300
60x120             6,740 8,010 10,500 12,800
80x100               8,010 10,500 12,800
80x120             7,770 9,173 12,091 14,682 17,026
80x140               9,990 13,108 16,532 18,803
80x160               11,030 14,810 17,643 21,023
100x140               11,030 14,810 17,643 21,023
100x150               11,500 15,300 19,000 21,616
100x200               14,100 18,720 22,455 26,798
150x200               15,990 21,230 26,403 31,535
150x250                 24,200 29,900 37,200
200x300                 30,500 37,800 47,100

KARE PROFİLLER BİRİM AĞIRLIK TABLOSU

Ebat Et Kalınlığı
  0,8mm 0,9mm 1,00mm 1,2mm 1,5mm 2,00mm 2,5mm 3,00mm 4,00mm 5,00mm 6,00mm
10x10 0,231 0,257 0,282 0,338
15x15 0,356 0,399 0,438 0,516 0,632
20x20 0,482 0,539 0,595 0,708 0,868 1,120
25x25 0,608 0,681 0,753 0,896 1,100 1,440 1,800 2,160
30x30 0,733 0,822 0,909 1,085 1,340 1,750 2,190 2,360
35x35     1,070 1,267 1,570 2,070 2,540 2,860
40x40   1,096 1,218 1,462 1,810 2,380 2,930 3,330 4,250 5,310
50x50   1,616 2,020 2,660 3,290 3,760 4,820 6,430
60x60 2,190 2,730 3,640 4,500 5,220 6,760 8,130
70x70 3,190 4,260 5,290 6,160 8,020 9,700
75x75 4,580 5,680 6,630 8,650 10,500
80x80             6,070 7,100 9,280 11,300
90x90           5,520 6,860 8,040 10,500 12,800
100x100               8,990 11,800 14,400 17,390
110x110               9,860 13,060 16,170 19,130
120x120               10,820 14,310 17,730 21,150
125x125               11,270 14,890 18,440 22,020
150x150               13,590 17,940 22,270 26,550
175x175                 21,090 26,050 31,030
200x200                 24,200 29,200 37,200
250x250                 30,500 37,800 47,100
Teklif için 0 212 546 70 30 numaralı telefondan ya da info@dmrdemir.com adresinden bize ulaşabilirsiniz.
